It’s a Snap!

gpsnap and gpcronsnap are new utilities for Pivotal Greenplum on AWS. These utilities leverage Amazon EBS Snapshots to take very quick snapshot backups.

EBS Snapshot
Elastic Block Storage (EBS) is the preferred storage in Amazon AWS for many reasons like persistence, performance, and high availability. A great feature of EBS is the ability to take a “Snapshot”. A snapshot can be taken of a disk volume and to get a consistent backup, you need to stop the database, take a snapshot of every volume, and then restart the database.

EBS Restore
The restore process requires stopping the database, detaching and deleting the existing volumes, creating new volumes from the snapshots, attaching the volumes to the right nodes, mounting the new volumes to the right directories, and then starting the database. If you don’t delete the existing volumes and just create new ones, you will incur more storage cost in AWS and you may hit your disk quota. So take a snapshot before you execute a restore so you can revert back if needed.

gpsnap makes this entire process easy. It does all of the tasks needed to take a consistent snapshot of the database. It also automates the tasks for restoring from a snapshot.

The commands include:
– gpsnap list: lists snapshots
– gpsnap create: creates a new snapshot
– gpsnap delete : deletes a specific snapshot
– gpsnap delete all: deletes all snapshots
– gpsnap restore : restores a specific snapshot

gpcronsnap is the second utility and you can probably guess from the name that it is the scheduling portion of the utility. By default, a snapshot backup will be created weekly and retain up to four snapshots. This is all configurable in a configuration file too.

So you can see, it is now a snap for Pivotal Greenplum on AWS to take snapshot backups!

You can either Bring Your Own License (BYOL) or pay Hourly for Greenplum on AWS. Here are the links:
Pivotal Greenplum on AWS (BYOL)
Pivotal Greenplum on AWS (Hourly)

Pivotal Greenplum Version 5.x

Version 3.x
I’ve been using Greenplum since version 3.0 back in 2007. That version was actually the first commercially available version too. The versions were released about once every 6 to 12 months and got as high as 3.3.

Version 4.x
Once the version got to 4.3, the number just seemed to get stuck. 4.3.0 was a pretty big release which changed “Append Only” tables to be “Append Optimized” which simply meant you could start updating and deleting tables stored in the append-only format. But more enhancements came to 4.3 but the version number never exceeded 4.3.

Labs Methodology
Major enhancements came to version 4.3.x and the innovation came at a faster pace but you may not have noticed this if you were just looking at the version number. Pivotal’s engineering team embraced the Pivotal Labs methodologies of pair programming and quick iterations. There was a huge transformation happening in this group.

Version 5.x
When 5.0 came out, it was a big deal. Greeplum had always been a fork of PostgreSQL 8.2 but with 5.0, Greenplum was rebased to 8.3. A lot of work went into this change which also requires migrating from 4.3.x to 5.0.

Now this next change, I didn’t expect. During the 4.3.x development, the only time the version number would change to either 4.4 or 5.0, it would be when the database required a migration to upgrade. With 5.x, the version numbers are coming fast and don’t require migrations to upgrade. It just a simple binary swap to upgrade.

The result has been the release of 5.0 on 2017-09-14, 5.1 on 2017-10-20, and 5.2 on 2017-11-18. Do you see the pattern? Monthly point releases! All of these releases so far have been simple binary upgrades but have a ton of improvements each time.

Version 6.0?
Version 6 is in sight. Seriously. I would expect this to be the next rebase of Greenplum to PostgreSQL 8.4 and will require a database migration to upgrade. It is amazing how the Labs culture and open source software development has enhanced the development of Greenplum.

AWS Marketplace

I haven’t posted much here lately because I’ve been working on deploying GemFire and Greenplum in the AWS Marketplace. It has been interesting work so I thought I would make a post about it here.

Amazon Web Services (AWS)
Amazon has the most popular cloud in the US with many products available which now includes Pivotal Greenplum and Pivotal GemFire. Both products are available as Bring Your Own License (BYOL) or Billed Hourly. BYOL simply means you already own a license and you wish to apply this to a deployment in AWS.

If you are not familiar with AWS, there are many ways to configure resources which can be overwhelming to learn and optimize. I have done extensive testing in these product offerings to ensure stability, security, repeatability, and performance. With just a few clicks, you can have an on-demand cluster built that rivals a full rack of on-premise hardware.

Greenplum and GemFire on AWS
Greenplum Billed Hourly
Greenplum Bring Your Own License (BYOL)
GemFire Billed Hourly
GemFire BYOL

Dropping Corrupt Tables in Greenplum

Greenplum is a Massively Parallel Processing database which means the data is distributed across multiple segments on multiple hosts. Each segment process stores a catalog of objects and it is possible to get this out of sync because of hardware failures or killing processes. For example, if you are vacuuming a table and then decide to kill the process on the Master host, the segments may not get the signal properly and rollback the transaction. This can happen when using “kill -9” rather than just “kill” to stop a process.

You may get this error message if a table is corrupt:

gpadmin=# select * from corrupt;
ERROR:  relation with OID 109802 does not exist  (seg0 slice1 gpdbsne:40000 pid=78502)

So you decide to drop the table and start over but that doesn’t work either.

gpadmin=# drop table corrupt;
ERROR:  table "corrupt" does not exist  (seg0 gpdbsne:40000 pid=78502)

The easy fix for this is to use “if exists” in the drop command.

gpadmin=# drop table if exists corrupt;
Time: 10.423 ms

Now the table is gone and you can recreate it. Next time, don’t use kill -9 and don’t kill vacuum commands.

More Details
If you are wondering how I managed to corrupt this table, here are the steps.
1. Create the table

gpadmin=# create table corrupt (id int, foo text, bar text) distributed by (id);
Time: 31.195 ms

2. Insert some data

insert into corrupt select i as id, 'foo_' || i, 'bar_' || i from generate_series(1,100) as i;
INSERT 0 100
Time: 46.419 ms
gpadmin=# analyze corrupt;
Time: 108.193 ms
gpadmin=# \q

3. Connect to a segment directly. I’m using a single node for this test.

[gpadmin@gpdbsne ~]$ ps -ef | grep postgres | grep M
gpadmin   78213      1  0 09:49 ?        00:00:00 /usr/local/greenplum-db- -D /data/primary/gpseg1 -p 40001 -b 3 -z 2 --silent-mode=true -i -M mirrorless -C 1
gpadmin   78214      1  0 09:49 ?        00:00:00 /usr/local/greenplum-db- -D /data/primary/gpseg0 -p 40000 -b 2 -z 2 --silent-mode=true -i -M mirrorless -C 0
gpadmin   78239      1  0 09:49 ?        00:00:00 /usr/local/greenplum-db- -D /data/master/gpseg-1 -p 5432 -b 1 -z 2 --silent-mode=true -i -M master -C -1 -x 0 -E

I see that the segments are using ports 40,000 and 40,001 while the master is using 5432. I’ll connect to seg0 on port 40,000 and then drop the table. This only drops the object in this one segment. I’ll also do a quick query to make sure I only see half of the data because I have 2 segments.

PGOPTIONS='-c gp_session_role=utility' psql -p 40000
psql (8.2.15)
Type "help" for help.

gpadmin=# select count(*) from corrupt;
(1 row)

Time: 3.485 ms

4. Corrupt the database by dropping the table only on one segment.

drop table corrupt;
Time: 9.410 ms
gpadmin=# \q

5. Confirm that the table is corrupt.

[gpadmin@gpdbsne ~]$ psql
Timing is on.
psql (8.2.15)
Type "help" for help.

gpadmin=# select * from corrupt;
ERROR:  relation with OID 109802 does not exist  (seg0 slice1 gpdbsne:40000 pid=78502)

And again, the fix:

gpadmin=# drop table if exists corrupt;
Time: 10.423 ms

S3 External Tables

S3 is Amazon’s Simple Storage Service which is an inexpensive cloud storage solution and has quickly become a solution for cold data and backups. Greenplum now has External Tables that can read and write data to S3 so you can leverage this popular storage service with Greenplum. Here is how you do it!

1. You will need an Amazon account with your Access Key ID and Secret Access Key. If you have the aws CLI installed and configured, just cat ~/.aws/credentials

2. Get your default region. This is in ~/.aws/config

3. You’ll need a bucket in this region and this can be done with the AWS web interface.

4. You’ll need a configuration file. Here is an example (be sure to change the secret and accessid).

secret = <secret>
accessid = <accesssid>
threadnum = 4
chunksize = 67108864
low_speed_limit = 10240
low_speed_time = 60
encryption = true

5. Copy the configuration to every Segment Host in your cluster.

for i in $(cat segment_hosts.txt); do scp s3_demo.conf $i:/home/gpadmin; done

Writing to S3

1. Create the Writable External Table with the S3 protocol, AWS URL that has the correct region, and the configuration file that is found on every Segment Host.

(id int, fname text, lname text)
LOCATION ('s3:// config=/home/gpadmin/s3_demo.conf')

2. Execute an INSERT statement:

INSERT INTO demo_write
SELECT i, 'Jon_' || i, 'Roberts_' || i
FROM generate_series(1,10000) as i;

Note: Each Segment will create a file in S3 in your bucket with the prefix you specify in the location specified in the Writable External Table. In this demo, each file is prefixed with “demo”. An example filename is “demo9767abbb3.txt”.

Reading from S3
1. Create the External Table with the same location and configuration as before.

CREATE EXTERNAL TABLE public.demo_read
(id int, fname text, lname text)
LOCATION ('s3:// config=/home/gpadmin/s3_demo.conf')

2. Select the data.

gpadmin=# select * from demo_read limit 10;
 id  |  fname  |    lname
  58 | Jon_58  | Roberts_58
  90 | Jon_90  | Roberts_90
 122 | Jon_122 | Roberts_122
 191 | Jon_191 | Roberts_191
 207 | Jon_207 | Roberts_207
 239 | Jon_239 | Roberts_239
 271 | Jon_271 | Roberts_271
 319 | Jon_319 | Roberts_319
 335 | Jon_335 | Roberts_335
 351 | Jon_351 | Roberts_351
(10 rows)

Time: 1139.538 ms

1. An S3 External Table that references a single file will only use a single Segment to read the data. Instead, try to have at least 1 file per Segment for an S3 External Table.
2. S3 External Tables supports gzip compression only.
3. Use S3 External Tables for cold storage or to create a backup of a table or query using a Writable External Table.

Greenplum Append Optimized Tables

Greenplum has two major types of table storage techniques. The first is inherited from PostgreSQL so it uses Multi-Version Concurrency Control (MVCC) and is referred to as HEAP storage. The second is more efficient technique called Append Optimized (AO). This blog post discusses the performance benefits of AO over HEAP tables.

This is the default storage technique when you create a table in Greenplum. It handles UPDATE and DELETE commands just like PostgreSQL in terms of marking the old row invalid and inserting a new record into the table. This hides the deleted or stale row for new queries but provides read consistency to sessions that may have started querying the table prior to the UPDATE or DELETE.

Here is an example of a HEAP table.

CREATE TABLE heap_table
(id int,
 fname text,
 lname text,
 address1 text,
 address2 text,
 city text,
 state text,
 zip text)

But how does this HEAP table store data? How much space does it use?

INSERT INTO heap_table (id, fname, lname, address1, address2, city, state, zip)
SELECT i, 'Jon_' || i, 'Roberts_' || i, i || ' Main Street', 'Apartment ' || i, 'New York', 'NY', i::text
FROM generate_series(1, 10000) AS i;

ANALYZE heap_table;

SELECT sotdsize
FROM gp_toolkit.gp_size_of_table_disk
WHERE sotdschemaname = 'public'
AND sotdtablename = 'heap_table';


So it uses 1,114,112 bytes in my small single node test for this generated data of 10,000 records.

AO storage was originally designed to be Append Only but starting with Greenplum version 4.3, these tables became Append Optimized because the tables now allow UPDATE and INSERT like a HEAP table but retain the efficient storage.

Create the same table and data but as an AO table.

(id int,
 fname text,
 lname text,
 address1 text,
 address2 text,
 city text,
 state text,
 zip text)
WITH (appendonly=true)

INSERT INTO ao_table (id, fname, lname, address1, address2, city, state, zip)
SELECT i, 'Jon_' || i, 'Roberts_' || i, i || ' Main Street', 'Apartment ' || i, 'New York', 'NY', i::text
FROM generate_series(1, 10000) AS i;

ANALYZE ao_table;

SELECT sotdsize
FROM gp_toolkit.gp_size_of_table_disk
WHERE sotdschemaname = 'public'
AND sotdtablename = 'ao_table';


This is now only using 973,016 bytes or a 12.6% reduction in disk space being used. For large tables, the performance difference will be more noticeable because it will take less time to scan your disks.

AO tables also let you compress it where a HEAP table does not. What does that look like?

CREATE TABLE ao_compressed_table
(id int,
 fname text,
 lname text,
 address1 text,
 address2 text,
 city text,
 state text,
 zip text)
WITH (appendonly=true, compresstype=quicklz)

INSERT INTO ao_compressed_table (id, fname, lname, address1, address2, city, state, zip)
SELECT i, 'Jon_' || i, 'Roberts_' || i, i || ' Main Street', 'Apartment ' || i, 'New York', 'NY', i::text
FROM generate_series(1, 10000) AS i;

ANALYZE ao_compressed_table;

SELECT sotdsize
FROM gp_toolkit.gp_size_of_table_disk
WHERE sotdschemaname = 'public'
AND sotdtablename = 'ao_compressed_table';


Dropped more to 234,344 bytes. This is a huge decrease in disk space being used and measures at another 75.9% reduction! This is trading CPU cycles for IO scans which in most cases, will provide better query times.

In the last test, make the table also column oriented. This is also a feature only available for AO tables.

CREATE TABLE ao_co_compressed_table
(id int,
 fname text,
 lname text,
 address1 text,
 address2 text,
 city text,
 state text,
 zip text)
WITH (appendonly=true, compresstype=quicklz, orientation=column)

INSERT INTO ao_co_compressed_table (id, fname, lname, address1, address2, city, state, zip)
SELECT i, 'Jon_' || i, 'Roberts_' || i, i || ' Main Street', 'Apartment ' || i, 'New York', 'NY', i::text
FROM generate_series(1, 10000) AS i;

ANALYZE ao_co_compressed_table;

SELECT sotdsize
FROM gp_toolkit.gp_size_of_table_disk
WHERE sotdschemaname = 'public'
AND sotdtablename = 'ao_co_compressed_table';


It dropped again! This time to 196,840 bytes or another 16%.

The total percentage difference between a HEAP table and the AO table that is column oriented and compressed is 82.33%!

Use AO tables. These are faster than HEAP tables and also let you compress and column orient your larger tables for even better performance.

Pivotal HDB 2.0.1 Configuration Tips

Here are some tips for configuring Pivotal HDB (based on Apache HAWQ) with Ambari.

Temp Directories
A Hadoop cluster typically is configured with JBOD so utilize all data disks for temp space.

Here is an example of the “HAWQ Master Temp Directories” entry when the Master and Standby nodes each have 8 disks:


Here is an example of the “HAWQ Segment Temp Directories” entry when each Data Node has 8 disks:


VM Overcommit
VM Overcommit set to 2

VM Overcommit Ratio
2GB – 64GB: set the Overcommit Ratio to 50
>= 64GB of RAM: set the Overcommit Ratio to 100

Swap Space
2GB – 8GB: set swap space equal to RAM
8GB – 64GB: set swap space to 0.5 * RAM
>= 64GB: set swap space to 4GB

Segment Memory Usage Limit
Step 1: Calculate total memory (RAM * overcommit_ratio_percentage + SWAP)
Step 2: Calculate total memory used by other activities (2GB for OS, 2GB for Data Node, 2GB for Node Manager, 1GB for PXF)
Step 3: Subtract other memory from total memory to get the value for the Segment Memory Usage Limit

Example 1:
RAM: 256GB
Other: 7GB
Overcommit Ratio: 100

Using Yarn: ((256 * 1) + 4) – 7 = 253
Using Default Resource Manager: (256 * 1) – 7 = 249

Example 2:
Other: 7GB
Overcommit Ratio: 50

Using Yarn: ((64 * 0.5) + 32) – 7 = 57
Using Default Resource Manager: (64 * 0.5) – 7 = 57

HDFS core-site.xml

ipc.client.connect.timeout = 300000


ipc.client.connection.maxidletime = 3600000

Optional HAWQ hawq-site.xml

hawq_rm_stmt_vseg_memory = 1gb

By default, this is set to 128mb which is great for a high level of concurrency. If you need to utilize more memory in the cluster for each query, you can increase this value considerably. Here are the acceptable values:

128mb, 256mb, 512mb, 1gb, 2gb, 4gb, 8gb, 16gb

Alternatively, you can set this at the session level instead of the entire database.

Operating System gpadmin account
Log into the Master and Standby nodes and execute the following:

echo "source /usr/local/hawq/" >> ~/.bashrc

Now set the database password. Below, I am using ‘password’ as the password so set this based on your organization’s password policy. By default, gpadmin doesn’t have a password set at all.

psql -c "alter user gpadmin password 'password'"

Enable encrypted password authentication. This assumes you are using the default /data/hawq/master path. Adjust if needed. This allows you to connect to the database remotely with an encrypted password.

echo "host all all md5" >> /data/hawq/master/pg_hba.conf
hawq stop cluster -u -a
